A.1 Specifications SDI inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HD-SDI follows the SMPTE 292M standard.
3G SDI follows the SMPTE 425M standard Level A.
12G-SDI
7
follows the SMPTE ST-2082-1 and ST-2082-10 standards.
SDI specifications
Specification
Value
Color space YCbCr
Color depth 10 bpc
Chroma sampling 4:2:2
Audio not supported
For future release
• 3D support
• Interlaced support
• Segmented frame support
Video timings
progressive
8
Type Port type Format
HD-SDI Single link
Quad link
• Up to 1920 x 1080 @24 Hz
• Up to 1920 x 1080 @25 Hz
• Up to 1920 x 1080 @30 Hz
• Up to 1280 x 720 @50 Hz
• Up to 1280 x 720 @60 Hz
3G-SDI Level A
9
Single link
Quad link
Up to 2048 x 1080 @50 Hz
Up to 2048 x 1080 @60 Hz
3G-SDI
“BarcoLink”
Single link
Quad link
1920 x 1200 @50 Hz, @59.94 Hz and
@60 Hz
12G-SDI (Channel
A only)
Single link 3840 x 2160 @50 Hz and @60 Hz
4096 x 2160 @50 Hz and @60 Hz
12G-SDI
“BarcoLink 4k”
(Channel A only)
Single link 3840 x 2400 @50 Hz, @59.94 Hz and
@60 Hz.
A.2 Specifications HDMI inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
HDMI specifications
Specification
Value
Pixel rate 25 – 600 MHz pixel clock
HDCP support
• HDCP 1.x
Specifications
7. Quad Combo Input Mk II only.
8. For the full list of video timings, see Appendix user guide
9. Quad Combo Input Mk I only.
