R5911443 /08 UDM166
12.1 Status menu overview
How to access the status menu
While in the main menu, press Status.
Image 12–1 Main menu, status
The status menu is displayed.
Image 12–2 Example of the first page of the status menu
Swipe the screen left of right to swap between the Status pages.
Image 12–3 Example of the second page of the Status menu
What can be seen on the Status page?
• Connected source and signal details
• Display settings (e.g. display mode, transport delay, output resolution, etc)
• Projector power and environmental details (e.g. power, temperature, pressure, etc)
• Network status (e.g. host name, IP address, software version)
• Active function icons (e.g. warp, blend, files, etc). Active functions are highlighted, while inactive functions
are muted.
GUI – Status menu
