Barco UDM User Manual

R5911443 /08 UDM22
2.1 Getting to know the projector
Orientation convention
This manual refers to the left side of the projector as the side at your left hand when standing behind the
projector and looking at the projection screen in front of the projector.
T
L
F
R
B
Image 2–1
T Top
L Left
F Front
R Right
B Back
Projector component location
65
1
2 3 4 7 8
Image 2–2
1 Dust filter top air inlet
2 Dust filter side air inlet
3 Input & Communication module
4 IR receiver projector right side
5 Dust filter front air inlet
6 Auxiliary connector (for external shutter, DMX, ...)
7 IR receiver projector front side
8 Distance meter (optional)
Getting Started
