Barco UDM User Manual

181R5911443 /08 UDM
2D Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
• Up to 2560 x 1600 @120 Hz
2D 2 column mode (2x1
layout)
• 1920 x 2160 @60 Hz
• 1920 x 2160 @120 Hz
• 1920 x 2400 @60 Hz
• 2048 x 2160 @60 Hz
• 2048 x 2160 @120 Hz
2D 4 quadrant mode (2x2
layout)
• 960 x 1080 @120 Hz
• 960 x 1200 @120 Hz
• 1280 x 1080 @60 Hz
• 1280 x 1080 @120 Hz
• 1280 x 1600 @60 Hz
• 1280 x 1600 @120 Hz
• 1920 x 1080 @120 Hz
• 1920 x 1200 @120 Hz
• 2048 x 1080 @120 Hz
2D 4 column mode (4x1
layout)
• 960 x 2160 @120 Hz
• 960 x 2400 @120 Hz
• 1024 x 2160 @60 Hz
Active 3D Standard layout (1x1
layout)
• 1600 x 1200 @120 Hz
• 2560 x 1080 @120 Hz
• 2560 x 1600 @120 Hz
Active 3D 2 column mode (2x1
layout)
1920 x 2160 @120 Hz
Active 3D 4 quadrant mode (2x2
layout)
• 1920 x 1080 @120 Hz
• 1920 x 1200 @120 Hz
• 2048 x 1080 @120 Hz
Active 3D 4 column mode (4x1
layout)
• 960 x 2160 @120 Hz
• 960 x 2400 @120 Hz
• 1024 x 2160 @120 Hz
Passive
stereo
Standard layout (1x1
layout)
3840 x 2160 @60 Hz
Passive
stereo
2 column mode (2x1
layout)
1920 x 2160 @60 Hz
Native video timings
• UDM-W: 1920 x 1200 @60 Hz
• UDM-4K: 3840 x 2400 @60 Hz
CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz) via the DP1.2
input, the quality of the cable must be adequate, in addition the length of the cable can also
influence the performance. In case there is an issue with one of these criteria the automatic link-
training initiated by the DP-standard may decide to switch to a lower resolution.
A.5 Specifications SFP inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
