145R5911443 /08 UDM
Option / Domain Setting Factory setting
Auto power down
Art-net
XLR Connector
Disabled
GSM PIN State Unconfirmed
Illumination Power 100%
Constant light output (CLO) Disabled
ImageActuator 4K Actuator enabled / disabled
Enabled
Blend Blend / Mask size
Black Level
Disabled, all value to zero
Black Level Files
Blend Files
Disabled.
Note: All uploaded blend and black level
files will be deleted
ImageCapture Camera Camera disabled, all measurements reset
to 0
Connectors Signal range Auto
Color space Auto
EDID Default EDID for projector type
Note: All uploaded custom EDID files will
be deleted.
Convergence Electronic Convergence All values to zero
Display Display mode AutoStereo
Image features Contrast mid value
Brightness mid value
Saturation mid value
Sharpness mid value
Gamma mid value, auto
Digital Shift and Zoom Disabled, set to mid values
Cropping Off
Aspect Ratio 16:9
Scaling Fill Aspect ratio
Orientation Orientation Table, Front
RealColor
TM
P7 P7 Realcolor
TM
all set to native
Resolution Output Resolution 4K UHD (4K devices)
WQXGA (W devices)
WUXGA (U devices)
Source Source files Standard
3D Sync delay 0 µs
Swap eye Off
Dark time lowest value available
Test patterns Test Pattern Off, none selected,
GUI – System Settings
