3. General
3.2 Covers
WARNING: Always install all co vers before using the chiller.
About the covers
Safety covers can be remo ved by a 3 mm hex screwdriver. It is advised to use an electric screwdriver due to the high amount of
screws each cover is attached with.
A
AAAA
Image 3-2
A
Fixed covers to prevent unwanted ac cess to ULC-30A parts and electric compon ents.
