5. Physical installation
F
Image 5-16
Connecting hose “F”
11.Install the insulation cover as illustrated.
Image 5-17
Installing t he insulation cover
5.2.6 Installation of the fan unit
Necessary tools
Nut spa nner 8 m m
How to install the fan unit?
1. Install the fan un it.
Image 5-18
Installing t he fan unit
2. Install the 6 screws (reference 1 image 5-19) using the nut s panner 8 m m.
