System description
8
Instruction Manual PETRO 3003 VOLUTANK Gauging unit BA 140918
3 System description
3.1 Construction of the gauging unit
Schematic structure
IN
Sight glass
Vent valve
Level sensor
Pump
Valve Y3
OUT1
OUT2
Valve Y4
Bypass
Valve Y2
