Instruction Manual PETRO 3003 VOLUTANK Gauging unit BA 140918
4.3.1.3 Gauging positions and setting for logical I/Os
The gauging unit must be connected differently (right/left) and certain logical
outputs will also need to be connected depending on the design of the vehi-
cle.
Left-left design (left fill | left discharge):
Left control (log. 14)
Right control (log. 20)
Direct outlet group valve (log. 9)

API manually open/close
