INSTALLATION AND USE MANUAL
SERVO DRIVE TYPE – DB21
M.DRIVE.DB-21.GEN.ENG
Ed.
2022
Rev.11
Pag.
15 di 34
6. DIPSWITCH SETTING (FOR TURRET TYPE SELECTION)
TURRET SELECTION
The setting of the turret type, the number of positions and dynamic profile must be performed before
starting the drive (24Vdc).
CUSTOM PROFILE
For nonstandard applications can be set via software a specific profile setting manually the
transmission
ratio (T.R.), number of stations and dynamic profile, in this case a red label will be applies on the
drive.
In order to replace the drive will be necessary reset the profile via p.c. on the new one.
The custom profile is added to the standard profiles.
TURRET
MODEL
1
2
3
TB-TBH-TC
N° pos
4
5
6
Profile
7
8
9
10
TB-TBH-TC 120/160
-
-
-
8
-
-
Voltage Selection
Univ.
-
-
Drive Set-up
Acquisition
TB-TBH-TC 200/250
-
-
12
-
Fast
-
TB 320
-
-
16
-
Medium
-
TB 400
-
24
Slow
TB 100
-
-
TAB
N° pos
4
5
TAB 210/265
4
(if set K3)
-
-
TAB 340/440
8
(if set K5)
-
-
6
(if set K3)
-
Custom
12
(if set K5)
-
24
(if set K5)
Dipswitch
ON
OFF
1 2 3 4 5 6 7 8 9 10
