Baruffaldi DB21 - SEQUENCE OF OPERATIONS N°2 (VOLTAGE SETTING); SEQUENCE OF OPERATIONS N°3 (TURRET CHARACTERISTICS)

INSTALLATION AND USE MANUAL
SERVO DRIVE TYPE – DB21
M.DRIVE.DB-21.GEN.ENG
Ed.
2022
Rev.11
Pag.
29 di 34
TURRET
MODEL
1
2
3
TB-TBH-TC
N° pos
4
5
6
Profile
7
8
9
10
TB-TBH-TC 120/160
-
-
-
8
-
-
Voltage Selection
Univ.
-
-
Drive Set-up
Acquisition
TB-TBH-TC 200/250
-
-
12
-
Fast
-
TB 320
-
-
16
-
Medium
-
TB 400
-
24
Slow
TB 100
-
-
TAB
N° pos
4
5
TAB 210/265
4
(if set K3)
-
-
TAB 340/440
8
(if set K5)
-
-
6
(if set K3)
-
Custom
12
(if set K5)
-
24
(if set K5)
Sequence of operations N°3:
1. With the drive still power OFF (24Vdc Off)
2. Set ON the dipswitches according to the turret
charaterist (see table below)
Sequence of operations N°2
(VOLTAGE SETTING)
1. Drive OFF (24Vdc Off)
2. Set OFF dipswitch n°6 if the input voltage
is 400V, set ON dipswitch n°6 if input voltage
is 230V.
Dipswitch
ON
OFF
1 2 3 4 5 6 7 8 9 10
220V
400V
Dipswitch
ON
OFF
1 2 3 4 5 6 7 8 9 10
Dipswitch
ON
OFF
1 2 3 4 5 6 7 8 9 10
