Fault Reporting BE1-11m
Table 33-2. Grouped Targets
Target
Targets in Group
Phase A
27P A
59P A
50 A
50 67 A
51 A
51 67 A
32 A
87 A
Phase B
27P B
59P B
50 B
50 67 B
51 B
51 67 B
32 B
87 B
Phase C
27P C
59P C
50 C
50 67 C
51 C
51 67 C
32 C
87 C
Phase G
50 G
50 67 G
51 G
51 67 G
Phase N
27X 3V0
27X Aux
59X 3V0
59X Aux
50 3I0
51 3I0
Phase G/N
All G and N
Positive Sequence
59X V1
50 I1
51 I1
Negative Sequence
59X V2
50 I2
51 I2
Retrieving Target Information and Resetting Targets
To view targets at the front-panel display, navigate to Metering > Status > Targets. The BE1-11m
provides target information from the most recent trip event. Target information is specific to an event; it is
not cumulative. Targets for previous events are recorded in the fault summary reports, which are
described in Fault Reports.
When a protective trip occurs and targets are logged, the front-panel Trip LED seals-in. The target can be
viewed on the front-panel display by navigating to Metering > Status > Targets.
To view target status using BESTCOMSPlus, use the Metering Explorer to open the Status, Targets
screen shown in Figure 33-4.
