10 Object directory
The following tables provide a summary of all objects supported by the encoder.
Object Object number in Hex
Name Object name
Format U/I = Unsigned/Integer, No. = no of bits, ARR = Array, REC = Record, STR = String
Access ro = read only, wo = write only, rw = read write, m = mappable
Default Default value on first init
Save X = can be stored in the EEPROM
Description Additional information
10.1 Communication Profile Area
Singleturn Encoders: 0001’0196h
Multiturn Encoders: 0002’0196h
Bit0 = Generic error
Bit3 = Temperature error
Bit4 = Communication error
Devicename =
“EAMxxx MT“
“EAMxxx ST“
Hardware version in ASCII
Software version in ASCII
No. of save possibilities 4
=“evas “ (0x65766173) to save
Application parameters
(Scaling, Direction)
=“evas “ (0x65766173) to save
Manuf. Specific parameters
(Default ECU-Address, Baudrate,
Group Extension)
=“evas “ (0x65766173) to save
Restore default parameters
No. of reset possibilities = 4
=“daol“ (0x64616F6C) to load
=“daol“ (0x64616F6C) to load
Manufacturer specific parameters
=“daol“ (0x64616F6C) to load
Product code:
70h = EAMxxx Multiturn Encoder
71h = EAMxxx Singleturn Encoder
