2.3.2.2 PowerSupplyandDigitalIOs
M8/3pins M8/4pins M8/8pins
1
4
3
1
2
4
3
8
5
7 3
1
4
2
6
1 (brown) Power V
CC
1 (brown) TrigIN+ 1 (white) Out 3
3 (blue) GND 2 (white) TrigIN- 2 (brown) In 2
4 (black) NC 3 (blue) Flash
out
3 (green) In 1
4 (black) U
ext
4 (yellow) IO GND
5 (green) IO Power V
CC
6 (pink) Out 1
7 (blue) Out 2
8 (red) In 3
