Baumer TXG - Standard Cameras with Power over Ethernet (Poe)

8
1.2 StandardCameraswithPoweroverEthernet(PoE)
Power over ethernet line ▪
Single cable solution for power, image data and parameterization ▪
External ▪ trigger possible
CameraType
Sensor
Size
Resolution
Full
Frames
[max.fps]
Monochrome/Color
TXG03-P / TXG03c-P 1/3" 656 x 494 / 656 x 490 90
TXG04-P 1/2" 656 x 494 56
TXG06-P / TXG06c-P 1/2" 776 x 582 / 776 x 578 64
TXG08-P / TXG08c-P 1/3" 1032 x 776 / 1032 x 772 28
TXG13-P / TXG13c-P 1/2" 1392 x 1040 / 1384 x 1036 20
TXG14-P / TXG14c-P 2/3" 1392 x 1040 / 1384 x 1036 20
TXG14f-P / TXG14cf-P 2/3" 1392 x 1040 / 1384 x 1036 30
TXG20-P / TXG20c-P 1/1.8" 1624 x 1236 / 1624 x 1232 16
TXG50-P / TXG50c-P 2/3" 2448 x 2050 / 2448 x 2050 15
Dimensions
26
26
36
36
4
x
M
3
36
36
26
8
x
M
3
57,7
2626
Photosensitive
surface of the
sensor
C Mount
Figure3►
Front and rear view of
a Baumer TXG camera
with Power over Ether-
net (PoE).
Figure4►
Dimensions of a
Baumer TXG camera
with PoE.
