Baumer TXG - 4.6.1.2 Configurable Outputs

47
(Input) Line 0
state high
state low
(Input) Line 2
state high
state low
(Input) Line 3
state high
state low
Trigger
Input 1
Input 2
IO Matrix
state selection
(software side)
Congurable4.6.1.2 Outputs
With this feature, Baumer offers the possibility of wiring the output connectors to internal
signals, which are controlled on the software side.
Hereby on TXG standard cameras, the output connector can be wired to one of pro-
vided internal signal "ExposureActive" (Flash), "User0", "TriggerReady", "TriggerOver-
lapped", "TriggerSkipped", "ReadoutActive" and "Timer1". Beside this, the output can be
disabled.
On TXGm3 cameras, the possible internal signals are "ExposureActive" (Flash), "User 0",
"User 1", "TriggerReady", "TriggerOverlapped", "TriggerSkipped" and "ReadoutActive".
Also here the outputs can be disabled.
(Output) Line 1
state high
state low
IO Matrix
state selection
(software side)
signal selection
(software side)
Exposu
re
Act
i
ve
U
s
e
r
0
T
im
er
1
OFF
Tr
i
gg
er
R
e
a
d
y
T
ri
g
g
e
r
O
v
e
r
l
a
ppe
d
T
r
ig
ge
r
S
k
ipp
e
d
R
ead
outAc
ti
ve
Internal Signals
◄Figure49
IO matrix of the
Baumer TXGm3 on in-
put side.
◄Figure50
IO matrix of the
Baumer TXG standard
camera on output side.
