Baumer VCXG .I - Mechanical Test Specifications

29
4.7 Mechanical Tests
Environmen-
tal Testing
Standard Parameter
Vibration,
sinusodial
IEC 60068-2-6 Frequency Range 10 - 2000 Hz
Amplitude under-
neath crossover
frequencies
1.5 mm
Acceleration 10 g
Test duration / Axis 150 min
Vibration,
broad band
IEC 60068-2-64 Frequency range
VCXG / VCXU
VCXG.I / .XT
20 - 1000 Hz
5 - 2000 Hz
Acceleration RMS 10 g
Test duration / Axis 300 min
Shock IEC 60068-2-27 Puls time 11 ms / 6 ms
Acceleration 50 g / 100 g
Number of shocks
per direction and
axis
10
Bump IEC60068-2-29 Pulse Time 2 ms
Acceleration 100 g
Number of bumps
per direction and
axis
5000
