7.6.7 Counter (≥Rel. 2 only)
You can choose between two counters (Counter Selector). With each of this counters you
can count the events in the table below. The count values of the events are readable and
writable.
With the feature Counter Trigger Source you can specify which event should be counted.
These events can also be used as a counter reset source.
These events are:
CounterEventSources
Counter2End FrameTrigger
ExposureActive Off
FrameTransferSkipped TriggerSkipped
You can set a counter duration too. You can therefore set the number of events to
be counted. When the set value is 0, then the maximum number of countable events
is 2
32
-1.
If you specify a value, then the counter counts up to that value and stops. Then a GigE
event is triggered ("Counter1/2End") and the status of the counter changes from ACTIVE
to the readable status COMPLETED.
Reset the counter
When the reset event is reached or the counter is reset by software with "Counter Reset",
