101
7.8 DeviceReset
The feature Device Reset corresponds to the turn off and turn on of the camera. This is
necessary after a parameterization (e.g. the network data) of the camera.
The interrupt of the power supply ist therefore no longer necessary.
7.9 User Sets
Four user sets (0-3) are available for the Baumer cameras of the VCX series. User set 0
is the default set and contains the factory settings. User sets 1 to 3 are user-specic and
can contain any user denable parameters.
These user sets are stored within the camera and can be loaded, saved and transferred
to other cameras of the VCX series.
By employing a so-called "user set default selector", one of the four possible user sets
can be selected as default, which means, the camera starts up with these adjusted pa-
rameters.
With the User Set Feature Selector you can select the features to store in the user set.
7.9.1 VCXG / .I/.I.XT
Parameter
AcquisitionFrameCount DeviceTemperature-
StatusTransition
PixelFormat
AcquisitionFrameRate EventNotication ReadoutMode
AcquisitionFrameRate-
Enable
ExposureMode ReverseX
AcquisitionMode ExposureTime ReverseY
ActionDeviceKey FixedPatternNoiseCorrec-
tion
SequencerMode (≥ Rel. 2)
ActionGroupKey FrameCounter SequencerSetNext (≥ Rel. 2)
ActionGroupMask Gain SequencerSetStart (≥ Rel. 2)
BalanceWhiteAuto Gamma SequencerTrigger-
Activation (≥ Rel. 2)
BinningHorizontal GevSCFTD SequencerTrigger-
Source (≥ Rel. 2)
BinningHorizontalMode GevSCPD TestPattern
BinningVertical Height TimerDelay
BinningVerticalMode LUTEnable TimerDuration
BlackLevel LineDebouncerHighTime-
Abs
TimerTriggerActivation
ChunkEnable LineDebouncerLowTimeAbs TimerTriggerSource
ChunkModeActive LineInverter TriggerActivation
ColorTransformation-
Value
LinePWMDuration
(VCXG.I /
.XT only)
TriggerDelay
CounterDuration LinePWMMaxDu-
ration
TriggerMode
CounterEventActivation LinePWMMaxDu-
tyCycle
TriggerSource
CounterEventSource LinePWMMode UserOutputValue
CounterResetActivation LineSource UserOutputValueAll
CounterResetSource OffsetX Width
DefectPixelCorrection OffsetY
