Baumer VCXG .I - Page 44

44
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXG-124M (.I / .I.XT) (IMX 304)
VCXU-124M
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXG-124C (.I / .I.XT) (IMX 304)
VCXU-124C
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXU-125M.R (IMX 226)
400 450 500 550 600 650 700
0
0.2
0.4
0.6
0.8
1.0
VCXU-125C.R (IMX 226)
Relative Response
Wave Length [nm]
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXG-201M.R (IMX 183)
VCXU-201M.R
400 450 500 550 600 650 700
0
0.2
0.4
0.6
0.8
1.0
VCXG-201C.R (IMX 183)
VCXU-201C.R
Relative Response
Wave Length [nm]
Figure19►
Spectral sensitivities for
Baumer cameras with
12.3 MP sensor.
Figure20►
Spectral sensitivities for
Baumer cameras with
12.3 MP sensor.
Figure21►
Spectral sensitivities for
Baumer cameras with
12.3 MP sensor.
