Troubleshooting
Compact manual b maXX
®
BM4400, BM4600, BM4700
Document no.: 5.06014.02 Baumüller Nürnberg GmbH
76
of 94
8.2
Error speed controller P0214
Error free control section P0215
Error CANsync P0216
Error no. Meaning Reaction Troubleshooting
208 Drive blocked IS Remove the blockade of the drive
209 Encoder 1 is parameterized as encoder
for the motor control, but the evaluation
is not activated. This error is also
shown, if the faulty positioning is in one
of the inactive data records.
IS You have got to either activate the encoder in
the encoder 1 (mode P0150) or you set the
encoder 2 as encoder for the position control
(parameter P1030)
210 Encoder 2 is parameterized as encoder
for the motor control, but the evaluation
is not activated. This error is also
shown, if the faulty positioning is in one
of the inactive data records.
IS You have got to either activate the encoder in
the encoder 2 (mode P0160) or you set the
encoder 1 as encoder for the position control
(parameter P1030)
211 Overspeed
Open loop
IS Check parameterization and reduce speed
212 to 223 not assigned = 0
Error no. Meaning Reaction Troubleshooting
224 to 234 Not assigned = 0 adjustable
235 Torque coupling: General error in the
master
adjustable
236 Torque coupling: Operating mode in
the slave is not speed control
IS
237 C onfiguration error reaction return
motion is invalid
IS
238 Return motion destination was not rea-
ched
adjustable
239 Application error
(enabled by P0302 bit 1)
adjustable
Error no. Meaning Reaction Troubleshooting
240 to 245 not assigned = 0 no reaction Check the parameterization of the
DC-parameters, see parameter manual
246 Invalid DIP switch settings according
to setting
Correct the wrong setting of the
DIP switch on the module
247 to 255 not assigned = 0
