DS-RPC OWNER’S MANUAL
APPENDIX C
__________________________________________________________________________________________
80
APPENDIX C
Ø Click the “Save Password” box in the “Connect” screen.
Ø Enter the telephone number of the unit you are dialing.
Ø Enter the location you are dialing from, usually Default Location.
Ø Click “Dial Properties.” Select the dialing properties from your
current location.
Ø Click “OK.”
Ø Click “Connect.”
POST DIAL TERMINAL SCREEN
NOTE: You may want to set up the DS73TP module to auto-
connect at dial-up. If not auto connected, you must select the port
from the DS71 or DS71-MD2 module main menu. If you are auto-
connected, and decide not to enter the module, type the attention
character five times to return to the DS71 or DS71-MD2 module
main menu.
Ø After a successful connection is established, select the DS73TP
module. The following menu appears:
Ø DS73TP Ethernet Module F.0.02
Ø Copyright (C) 1997
Ø Bay Technical Associates
Ø Press F7. Windows 95 Dialer enters the user name and password.
Ø Enter User Name: user1
Ø Enter Password: BTA
Ø Login successful.
Ø Use your web browser, FTP, TELNET, or any TCP/IP application to
communicate on the network.
