MX610HD User’s Manual
20 MX610HD User’s Manual
Before installing the CPU, make sure that
towards you and the load lever is on your left.
2. Press the load lever with your thumb (A), then move it to the left (B) until it is released
from the retention tab.
To prevent damage to the socket pins, do not remove the PnP cap
unless you are installing a CPU.
3. Lift the Load lever with your thumb and forefinger to around 120º angle (C), then pull the
PnP cap from the CPU socket to remove (D).
To Next Page
