BCM RX170Q - 1.3 Central Processing Unit (CPU)

RX170Q User’s Manual
RX170Q User’s Manual
17
COM1 ~ 5
Serial Port Connector
5 x 2 header, pitch 2.00mm
SATA1 ~ 6
SATA Data Connector
7P Male connector
USB910/1112
USB Connector
5 x 2 header, pitch 2.54mm
LPT1
Print Port Connector
13 x 2 wafer, pitch 2.54mm
USB56
USB 3.0 connector
10 x 2 header, pitch 2.54mm
JBKL1
Backlight connector
5 x 1 wafer, pitch 2.00mm
CN3
LVDS connector
40 x 2 wafer, pitch 1.25mm
JSMB1
SM bus connector
3 x 1 header, pitch 2.00mm
MINI_CARD1
Mini PCIe connector
Support full/half length
miniPCIe card
NGFF1
M.2 connector
1.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1151 socket designed for the Intel®
Core™ i7/ i5/ i3 processor in the 1151-land package.
 Your boxed Intel® Core™ i7/ i5/ i3 LGA1155 processor package
should come with installation instructions for the CPU, fan and
heatsink assembly. If the instructions in this section do not match
the CPU documentation, follow the latter.
 Upon purchase of the motherboard, make sure that the PnP cap
is on the socket and the socket pins are not bent. Contact your
retailer immediately if the PnP cap is missing, or if you see any
damage to the PnP cap/socket pins/motherboard components.
BCM Advanced Research will shoulder the cost of repair only if
the damage is shipment/transit-related.
 Keep the cap after installing the motherboard. BCM Advanced
Research will process Return Merchandise Authorization (RMA)
requests only if the motherboard comes with the cap on the
LGA1151 socket.
 The product warranty does not cover damage to the socket pins
resulting from incorrect CPU installation/removal, or
misplacement/loss/incorrect removal of the PnP cap.
 Install the CPU fan and heatsink assembly before you install
motherboard to the chassis.
If you purchased a separate CPU heatsink and fan assembly, make
sure that you have properly applied Thermal Interface Material to the
CPU heatsink or CPU before you install the heatsink and fan
