RX170Q User’s Manual
RX170Q User’s Manual
29
1
1
AT mode
ATX mode
(Default)
1.6.3 COM POWER SETTING (JCOMPWR1~5)
This jumper allows you to select COM2 to support Ring/+12V/+5V
Ring
+12V
1 2
+5V
1 2
1 2
