B-29
Using a Stacker Carousel (Windows 7 Only)
Framing the Stacker Carousel
B
Removing Stacker Carousels
to remove Stacker Carousels:
1
In Hardware Setup, right-click the desired device under Stacker Carousels.
2
Choose Remove Device. The device is removed from the installed stackers under Stacker
Carousels in the left pane.
OR
1
Select the desired stacker under Stacker Carousel.
2
Choose Remove Device from the top of Hardware Setup. The device is removed the installed
devices under Stacker Carousels in the left pane.
Framing the Stacker Carousel
The Stacker Carousel is framed using the AccuFrame and the Framing Tool Adaptor.
To frame the Stacker Carousel:
1
Using the Control Pendant, choose SHUTTLE IN and SHUTTLE OUT to ensure the shuttle of the
Stacker Carousel is in the correct position for framing. The shuttle should be out for framing.
NOTE Refer to the Stacker Carousel User’s Manual (PN 148598) for more information on using the
Control Pendant.
CAUTION
CAUTION: To prevent damage to the shuttle, first place the AccuFrame into the
Framing Tool Adaptor. Then place the AccuFrame with the attached adaptor on
the shuttle.
2
Manually place the AccuFrame into the Framing Tool Adaptor by placing the front right corner
first and pushing the AccuFrame gently down into the adaptor (
Figure B.32).
