Framing Instructions
Framing the Gripper
3
3
Once the tip is just touching the target position, select Finish. The pod moves up to its maximum
height in the Z-axis,
Manual Teaching closes, and Position Properties appears (Figure 3.9).
4
Choose OK to save the framing information and close Position Properties.
5
Repeat the procedure to frame additional deck positions using manual teach.
6
Choose Save to save framing information for all positions and close the Deck Editor (Figure 3.8).
NOTE Choosing Cancel loses all changes to the deck, including framing information, since the Deck
Editor was opened.
Framing the Gripper
A Beckman Coulter Service Engineer frames the gripper during system installation; however, it may
be necessary to repeat the framing procedure if:
• the head is changed.
• gripper fingers are replaced.
• extraordinary circumstances occur, such as accidentally bending a gripper.
Before framing the grippers, make sure:
• instrument is homed (refer to Homing All Axes of the Pods).
• deck position is framed prior to framing the gripper to that location (refer to Framing Deck
Positions on the Biomek NX Using AccuFrame).
• AccuFrame is installed on the appropriate position (refer to Installing AccuFrame).
• framing fixture is not attached to the Multichannel Pod.
To frame the grippers:
1
Choose Start > Programs > Beckman Coulter > Biomek Software to start the Biomek Software.
2
From the Instrument menu, choose Hardware Setup. Hardware Setup appears.
3
Choose the Multichannel Pod. The configuration to frame the gripper appears on the right
(
Figure 3.18).
