987892AF
3-6
Framing Instructions
Framing Deck Positions on the Biomek NX Using AccuFrame
WARNING
Make sure the light curtain is not violated by the AccuFrame cable. If the light
curtain is violated, the framing process halts immediately.
WARNING
Make sure the AccuFrame cable does not interfere with pod movement.
3
Turn on power to the Biomek NX instrument.
4
Manually place the AccuFrame onto the ALP position that requires framing by placing the back
right corner first and pushing the AccuFrame gently down onto the ALP position.
NOTE The deck is usually framed from left to right, starting at the back left position. However, ALPs may
be framed in any order.
5
Make sure that the AccuFrame is fully seated along the posts along the top and right sides of the
position.
NOTE Some ALPs require a framing adaptor to accommodate using AccuFrame to frame the position.
Make sure the correct adaptor is used for each type of ALP. Framing proceeds as normal once the
AccuFrame is placed on the appropriate adaptor.
Framing the Position
To frame the Biomek NX deck position:
NOTE Some ALPs require additional or slightly modified procedures to frame properly. Refer to the
Automated Labware Positioners (ALPs) Instructions For Use (987836) for the specific ALP to frame for any
special framing instructions.
1
In Biomek Software, choose Instrument > Deck Editor. Deck Editor appears (Figure 3.4).
