BECS BECSys3 - Section K: Replacement Parts

Page 30
www.becs.com 9487 Dielman Rock Island Ind Dr, St. Louis, MO 63132
Installation and Technical Manual Rev: H10
S
S
e
e
c
c
t
t
i
i
o
o
n
n
K
K
:
:
R
R
e
e
p
p
l
l
a
a
c
c
e
e
m
m
e
e
n
n
t
t
P
P
a
a
r
r
t
t
s
s
Fuses
8140086
Main Fuse
Time Lag 250mA 250V
9140088
Relays 1-3
Time Lag 3A 250V
8140059
RS485 Fuse
Time Lag 250mA 250V
8320053
Fuse Cap
Sensors
pH Sensors
9660013
BECSys pH Sensor (30” cable) [range: 0 to 14.0 pH]
9660010
BECSys pH Sensor (10’ cable) [range: 0 to 14.0 pH]
ORP Sensors
9660022 BECSys ORP Sensor Platinum Band (30” cable)
[range: 0 to 1000mV]
9660023
BECSys ORP Sensor Platinum Band (10’ cable)
[range: 0 to 1000mV]
9660038 BECSys ORP Sensor Solid Gold Band (30” cable)
[range: 0 to 1000mV]
9660040
BECSys ORP Sensor Solid Gold Band (10’ cable)
[range: 0 to 1000mV]
pH/ORP Sensor Accessories
8500061
4/KCl solution (pint); for long-term storage of sensors
8680015
½” Wetting Cap for pH and ORP sensors
Temperature Sensors
9660016
Temperature Sensor (30” cable)
[range: 32°F to 212°F (0°C to 100°C)]
9660003 Temperature Sensor (10’ cable)
[range: 32°F to 212°F (0°C to 100°C)]
Flow Switches
9660006 Reed flow switch [Switch Point (On): 2.0 gpm]
9660007
Rotary flow switch [Switch Point (On): 1.5 gpm]
9060547
Spring Check Valve
8680019 Rotary Flow Switch Replacement Kit includes: 1 Pin,
1 Cover, 1 Wheel, 1 O-ring
8060663
Rotary Flow Switch Replacement Pin
8060664
Rotary Flow Switch Replacement Cover
8060665
Rotary Flow Switch Replacement Wheel
8060666
Rotary Flow Switch Replacement O-Ring
Amperometric ppm (Cl)
9660005
Amperometric Sensor only, no flow cell
[range: 0 to 20 ppm]
8680016 Replacement Membranes (2 pieces) for Chlorine
Sensor 9660005
8680017
Electrolyte (50 ml) for Chlorine Sensor 9660005
Boards
1200556
BECSys3 CPU PCB
1200407
BECSys3 Relay PCB
1200554
Free Chlorine (CCS140) Option Board
1200566
Free Chlorine (ECL6) Option Board
Software
M000104
BECSys3 Firmware Upgrade IC
Documentation
8620044
BECSys3 Operator’s Manual
8620045
BECSys3 Installation/Technical Manual
8620046
BECSys3 (no ppm scale) Quick Reference Sheet
8620047
BECSys3 (0.2 – 16.0 scale) Quick Reference Sheet
Misc
Enclosure Parts
M000099
BECSys3 Lid Assembly no ppm scale
M000101
BECSys3 Lid Assembly 0.2 – 16.0 ppm scale
8440199
BECSys3 Overlay no ppm scale
8440200
BECSys3 Overlay 0.2 – 16.0 ppm scale
9520027
Single BNC cable assembly
Internal Components
8041102
2 Position Pluggable Terminal Block (Temperature)
8041103 3 Position Pluggable Terminal Block (Flow Switch,
RS485)
8380650
RS485 IC
9060533
Shield Screws
9520034
Ribbon Cable
Flow Cell Replacement Parts
Round Flow Cell
1220210
Round Flow Cell Body
1220205
Acrylic Cover for Round Flow Cell
8060626
O-Ring for Round Flow Cell
1220207
PVC Mounting Plate for Round Flow Cell
8080625
Screws – Mounting Plate
Rectangular Flow Cell
1220201
2-Sensor Rectangular Flow Cell Body
1220200
Acrylic Cover for 2-Sensor Rectangular Flow Cell
8060669
O-Ring for 2-Sensor Rectangular Flow Cell
Common Flow Cell Components
9060189
Screws – Acrylic Cover
8060623
Elbow, 90° PVC
8060624
Elbow, 45° PVC
9060538
Plug, ¼” PVC
9060541
Nipple, ½” Close
8060621
Sample Valve, ¼” Ball Cock
9060546
Ball Valve ½” PVC
9060549
S80 Bushing, PVC ¾ x ½
9060544
Pressure Gauge
8060673
Pressure Regulator
Amperometric Flow Cell Components
1210255
Flow Cell for Amperometric Sensor (9660005)
8060671
Flow Meter used in Amperometric Flow Cell 1210253
