Pump element is suspended but not yet screwed in:
Fig. 27
F) Test whether the piston is correctly suspended. The pump element must not be able to be pushed up.
Fig. 28:
G) Tighten the pump element with the specified torque until the required position is reached.
Fig. 29:
INCORRECT
SW 24
45 Nm ±10%
