Installation GRS105/GRS106
Release
01
11/2021
43
Use the screws to secure the mounting brackets on the device.
Additionally attach 2 brackets to the rear of the device as shown in
figure 14.
You obtain the additional brackets as accessories.
See “Accessories” on page 73.
Fasten the device by screwing the brackets to the flat surface.
Completely screw the device to the flat surface using screws through
each mounting hole. Exclusively use screws suitable for the
installation and application case to ensure flawless operation of the
device.
Note: The device may be used as desktop device.
Mounting vertically on a flat surface
Note: Optionally, the device can be rotated by 90° to optimize ventilation:
Mount the device on a vertical flat surface with the ventilation slits at the
top and bottom of the device. See figure 15.
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to EN 62368-1 if you install
the device vertically.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
