TM 55-1520-228-BD
ELECTRICAL AND AVIONICS SYSTEM
Figure 11-7. Bolted Terminal Lug Repair of Large Wires
Figure 11-8. Replacement Section; Terminal Lug Repair
6. Ram or push the two wire ends together so
that the strands interlink.
7. Secure with screw clamp, control cable clamp,
safety wire, or other suitable means, Figure 11-9.
8. Insulate with tape or insulation sleeve.
9. Record BDAR action taken. When mission is
complete, as soon as practical, repair the
equipment/system using standard maintenance
procedures.
Figure 11-9. Ram Wire Repair Method
11-14
