TM 55-1520-244-BD
APPENDIX E
BDAR FIXES AUTHORIZED FOR TRAINING
BDAR FIXES SHALL BE USED ONLY IN COMBAT OR FOR TRAINING
AT THE DISCRETION OF THE COMMANDER.
(AUTHORIZED TRAINING FIXES ARE LISTED IN APPENDIX E.)
IN EITHER CASE, DAMAGES SHALL BE REPAIRED BY STANDARD
PROCEDURES AS SOON AS PRACTICABLE.
REPAIR PROCEDURE
AIRFRAME
Honeycomb Core Floor or Panel Damage . . . . . . . . .
DRIVE TRAIN SYSTEM
Air Duct Hose Damage . . . . . . . . . . . . . . . . .
HYDRAULIC SYSTEM
Lines and Hoses. . . . . . . . . . . . . . . . . . . .
Aluminum Tube Damage . . . . . . . . . . . . . . . . .
Hydraulic Hose Damage . . . . . . . . . . . . . . . . .
ELECTRICAL AND AVIONICS SYSTEM
Splicing Unshielded Wires . . . . . . . . . . . . . .
Damaged Wire Insulation . . . . . . . . . . . . . . .
Shielded Cable Repair . . . . . . . . . . . . . . . .
Shielded Cable Repair Segments . . . . . . . . . . . .
Shielded Terminators . . . . . . . . . . . . . . . . .
Terminators for Nickel-Plated Shields (including
vermillion). . . . . . . . . . . . . . . . . . . . .
Terminal Boards. . . . . . . . . . . . . . . . . . . .
Terminal Lugs. . . . . . . . . . . . . . . . . . . . .
Wire Bundle Tie Wraps.... . . . . . . . . . . . . .
Coax Splice for RG-136/U and RG-179 R/U. . . . . . . .
Bus Bars. . . . . . . . . . . . . . . . . . . . . . .
Battery Repair BB-476/A. . . . . . . . . . . . . . . .
Substitute Emergency Antenna, Field Expedient. . . . .
