Serial interfaces
58
TGH1361en/11.2009
BMS-bus address ranges
Addresses* Device Meaning
0
There is no device with address 0 !
Information sent to address 0 applies to all devices
connected to the interface (broadcast)
1 PRC1470 Control and indicating device
1...30
IRDH275B/
375B/575
Insulation monitoring device
1...30 FTC470... Protocol converter
2...30 EDS47x-12 Insulation fault evaluators (localisation)
31...60 SMO480-12 Signal converter relay
61...90 EDS47xE-12 Insulation fault evaluators (localisation)
111...119 PGH47x Test device for insulation fault location
121...150 PGH47xE Test device for insulation fault location
When assigning addresses, take care that there are no gaps greater
than five in the respective ranges (1...30, 31...60, 61...90, 111...119
and 121...151).
