Technical data IRDH275(B)
71
TGH1361en/11.2009
7.4.2 Coupling devices
Type Nominal voltage Art. No.
range U
n
AGH204S-4 AC 0...1650 V B 914 013
AGH520S AC 0...7200 V B 913 033
AGH150W-4 DC 0...1760 V B 9801 8006
7.4.3 Measuring instruments
Type Measuring range Dimensions Art. No.
7204-1421 0...400 µA 72 x 72 mm B 986 763
9604-1421 0...400 µA 96 x 96 mm B 986 764
7204S-1421 0...400 µA 72 x 72 mm B 986 804
9604S-1421 0...400 µA 96 x 96 mm B 986 784
9620-1421 0...20 mA 96 x 96 mm B 986 841
9620S-1421 0...20 mA 96 x 96 mm B 986 842
7.4.4 Label for modified versions
There will only be a label in this field if the A-ISOMETER® is different from
the standard version.
