Operation and setting
47
IRDH375_D00124_05_M_XXEN/01.2020
6.2 Menu structure and menu mode
Switchover to the menu mode
After pressing the MENU key, you can change from the standard mode to the
menu mode. From the menu mode you can link to the different sub menus.
Navigation within the menu
Select the desired menu item using the UP/DOWN keys. The selected menu
item is indicated by a flashing cursor. Press the ENTER key to open the associ-
ated sub menu.
Use the UP/DOWN keys again to select the desired parameters. Move the cur-
sor to the edit field by pressing the ENTER key.
If you have reached the end of the main menu list, it will be indicated by the
"Arrow UP" symbol.
Changing the parameters
When password protection is activated, indicated by the symbol "padlock
closed" , the first thing to enter is the correct password before the param-
eters can be changed using the UP/DOWN keys. Entering the correct pass-
word once allows all parameters to be changed as long as you do not leave
the menu.
Changing the parameter usually has an immediate effect on the measuring
and alarm functions. The changed parameter is stored in a volatile memory by
pressing the ENTER or ESC key after returning to the sub menu (flashing cursor
in column 1). During menu operations, all measuring and alarm functions car-
ry on working as usual in the background.
