Operation and setting
61
IRDH375_D00124_05_M_XXEN/01.2020
6.6.3 ISO monitor (IRDH375B)
This function allows to query the current measured value as well as the mes-
sages of all bus-capable ISOMETER®s existing in the BMS network. After select-
ing the bus address, the entire information stored by the selected device is
indicated on the display. The display indication is structured similar to the
standard indication, but instead of the indication of the measuring pulse, the
selected bus address is indicated. Without pressing a key, the indication
changes to the standard indication of the IRDH375B after about five minutes.
If there is no information available from the selected ISOMETER®, the message
"!!!!NO DATA!!!!" will be displayed.
Information is being searched
No data found
Current data address 03
<<Bus SCANNING>>
R= K ADR:02
!!!!NO DATA!!!!
R= K ADR:02
Insulation Fault
R= 010K ADR:03
