SettingsSettings
iso685-D-P_D00170_00_M_XXDE/06.2016
55
10.1 2.4.2.1.3 Function 1
Up to three functions can be assigned to one output. The functions are linked to an OR
operator:
Set the function for the outputs:
10.1 2.4.2.1.4 Function 2
Refer to “10.1 2.4.2.1.3 Function 1”.
10.1 2.4.2.1.5 Function 3
Refer to “10.1 2.4.2.1.3 Function 1”.
•off
The function is not used.
•I
ΔL
The status of the output changes if an insulation fault is
detected (EDS function) on one of the measuring chan-
nels.
•I
ΔN
The status of the output changes if the residual current
(RCM function) is exceeded.
•Device fault
The status of the output changes in the event of an inter-
nal device fault.
•Connection fault
The status of the output changes when one of the follow-
ing measuring current transformer connection faults
occurs:
Measuring current transformer defective
Power supply cable interrupted
Power supply cable short-circuited
•Insulation fault
location active
The buzzer signals active insulation fault location
can only be set for buzzer).
•Common alarm
The status of the output changes on the occurrence of any
alarms and fault messages (I
∆L
alarm, I
∆n
alarm, connec-
tion and device fault).
≥ 1
Response
Function 1
Function 2
Function 3
10.1 2.4.2.2 Buzzer
Select the buzzers that you would like to configure.
Now assign the events on which the buzzers should be triggered.
10.1 2.4.2.2.1 TEST
Refer to “10.1 2.4.2.1.1 TEST”.
10.1 2.4.2.2.2 Function 1
Refer to “10.1 2.4.2.1.3 Function 1”.
10.1 2.4.2.2.3 Function 2
Refer to “10.1 2.4.2.1.3 Function 1”.
10.1 2.4.2.2.4 Function 3
Refer to “10.1 2.4.2.1.3 Function 1”.
10.1 2.4.2.3 Digital output
Select the digital outputs of the EDS that you would like to configure.
Now make the settings for the digital outputs of the EDS selected before.
•Select all
All buzzers are selected.
•No selection
No buzzer is selected.
•Invert selection
The current selection is inverted.
•Buzzer 1 (BS 2/1)
A single buzzer is selected.
•Select all
All digital outputs are selected.
•No selection
No digital output is selected.
•Invert selection
The current selection is inverted.
•Dig. output 1 (BS 2/1)
A single digital output is selected.
