6.6 Connection to the supply voltage
External Power supply for powering the ISOMETER® via terminal X1 must
fulfil immunity and emission standards of the required application. For
wiring longer than 1 m the use of a shielded cable is prescribed.
Danger of damage to property due to faulty connections!
The device can be damaged if the unit is simultaneously connected to the
supply voltage via the X1 interface, and A1/+ and A2/- terminals. Do not
connect the device simultaneously via X1, and A1/+ and A2/- to different
supply voltages.
6.7 Connection to the Ethernet interface
Position the terminal cover and click it into place
