Bender ISOMETER iso685-D User Manual

SettingsSettings
iso685-D-B_D00177_05_M_XXEN/07.2017
40
10.1 (1.10.6.4) Function
Select the appropriate setting for the analogue output. The following parameters can be
set.
10.1 (2.0) Data measured values
The ISOMETER® stores certain measured values for a specific period of time. You can view
these data at the "Data meas. values" menu point. Navigate through the different views
using the and buttons:
•Insulation value
Depending on the measured insulation value, an analogue current
or voltage signal is provided at the output.
•DC offset
Depending on the measured DC offset, an analogue current or volt-
age signal is provided at the output. This setting can only be used
when Linear is selected in the menu "Midscale".
•isoGraph data
Displays the insulation resistance and chronological sequence.
See “Data-isoGraph” on page 28.
•Insulation data
Displays the current insulation resistance, the minimum insulation
resistance measured and the system leakage capacitance.
•IT system data
Displays the system phase-to-phase voltages and the mains fre-
quency (r.m.s. values)
•IT system data
Displays the system phase-to-earth voltages
DC+ alarm
Symmetrical alarm
DC- alarm
0 %
25 %
50 %
75 %
100 %
0 V/2 V
0 mA/4 mA
0 µA
10 V
20 mA
400 µA
10.1 (3.0) Control
In the control menu, you can start a manual test reset, reset alarm messages and start an
initial measurement:
10.1 (4.0) History
In the history menu, the faults detected by the ISOMETER® are displayed. For a detailed
functional description, refer to “History memory” on page 29.
10.1 (5.0) Device settings
The device settings menu allows you to configure the basic settings for the ISOMETER®.
10.1 (5.1) Language
Choose the language to be displayed by the ISOMETER®. For example, you can set the lan-
guages:
10.1 (5.2) Clock
In the clock menu you can set the display format of time and date for the ISOMETER®:
•TEST
Manual device test
•RESET
Reset of fault and alarm messages
•Start initial
measurement
All recorded measurements are discarded and a new measurement
is started
•History
Overview of faults that have occurred
•Delete
Reset the history memory
•German
•English
•...
