Technical dataTechnical data
iso685-D-B_D00177_05_M_XXEN/07.2017
63
17.2 Option "W"
Devices with the suffix "W“ feature increased shock and vibration resistance.
The electronics is covered with a special varnish to provide increased protection against
mechanical stress and moisture.
17.3 Standards and certifications
The ISOMETER® has been developed in compliance with the following standards:
• DIN EN 61557-8 (VDE 0413-8):2015-12
• IEC 61557-8:2014-12
• IEC 61557-8:2014/COR1:2016
• DIN EN 61557-8 Ber 1 (VDE 0413-8 Ber 1):2016-12
17.4 Ordering details
* Option "W": Increased shock and vibration resistance 3K5, 3M7; -40…+70 °C
Combination of ISOMETER® sensor variant with FP200:
The requirements of Option "W" will only be fulfilled when the ISOMETER®
sensor variant is mounted on DIN rail and connected to the FP200 via the
patch cable.
Refer also to the quick-start guide FP200 (Document number D00169).
Type
Supply voltage U
S
Art. No.
iso685-D-B
AC 24…240 V; 50…400 Hz
DC 24…240 V
B91067020
iso685W-D-B*
AC 24…240 V; 50…400 Hz
DC 24…240 V
B91067020W
Combination
iso685-S-B + FP200
AC 24…240 V; 50…400 Hz
DC 24…240 V
B91067220
Combination
iso685W-S-B + FP200W*
AC 24…240 V; 50…400 Hz
DC 24…240 V
B91067220W
Accessories
* included in the scope of delivery
** If the “transparent front cover 144x72 (IP65)” is used, the cutout in the control cabinet
must be increased in height from 66 mm to 68 mm (+ 0.7 / -0 mm).
Suitable system components
* Option "W": Increased shock and vibration resistance 3K5, 3M7; -40…+70 °C
**
SKMP = midscale point
Description Art. No.
iso685 Mechanical accessories comprising:
Terminal cover and 2 mounting clips*
B91067903
iso685 Plug kit, screw terminals* B91067901
iso685 plug kit, with push-wire terminals B91067902
Transparent cover 144x72 (IP65) for FP200 ** B98060005
Description Type Art. No.
Suitable measuring instruments
SKMP
**
: 28 kΩ,120 kΩ
Current values: 0…400 µA, 0…20 mA
(additonal information here)
7204-1421 B986763
9604-1421 B986764
9620-1421 B986841
Display for front plate mounting
FP200 B91067904
FP200W B91067904W
iso685-S
(only in combination with FP200)
Supply voltage:
AC 24…240 V; 50…400 Hz
DC 24…240 V
B91067110
iso685W-S*
(only in combination with FP200)
Supply voltage:
AC 24…240 V; 50…400 Hz
DC 24…240 V
B91067110W
