The web configuration page will be displayed.
Fig. 44: list of web interface settings
7th Click on the “Network” link.
The “Network Configuration” page is displayed.
Fig. 45: “Network Configuration” page
8th Check the network settings and make any changes in the text boxes if required.
ECC21XX Slim configuration: ETH0 = X4, ETH1 = X5
9th Save the settings by clicking on “Save”.
10th Additional settings can also be viewed and/or modified on the web configuration page (e.g. system
time, display resolution, TargetVisu).
