10.3. ECC21XX Slim Ethernet controller
Ethernet controller
ECC2100 Slim
ECC2110 Slim
Item no.
250000200
250001100
CPU, user memory
CPU
800 MHz ARM
®
CPU
Program memory (flash)
256 MB
Program memory and
data memory (RAM)
256 MB
Retain memory
100 kB (FRAM)
Dimensions and weight
Dimensions (WxHxD)
95 x 128 x 46 mm
Weight
approx. 550 g
Operating conditions
Surrounding temperature
0 °C to 55 °C (in compliance with installation requirements)
Relative humidity
max. 85%, non-condensing
Transport and storage
Ambient temperature
–20 °C to +70 °C
Relative humidity
max. 85%, non-condensing
Operation
Installation
on a mounting rail to DIN EN 60715:2001, 35 x 7.5 mm
Certification
to product standards DIN EN 61010-2-201, DIN EN 61131-2
Development environment
CODESYS V3 (IEC 61131-3)
Shock resistance
Vibration
sinusodial (EN 60068-2-6), test: Fc 10…150 Hz, 10 m/s²
Shock
15 G (approx. 150 m/s²), 11 ms duration, half-sine (EN 60068-2-27),
test: Ea
EMC, protection rating
Emitted interference
EN 61131-2; EN 61000-6-3, residential areas
Resistance to interference
EN 61131-2; EN 61000-6-2, industrial areas
Protection class
III
Protection rating
IP20
Power supply (24 V power)
Supply voltage
+24 V DC (–15 % / +20 %) SELV max. Alternating current proportion
