Instruction Manual
4545
5.8.2 Access via Bluetooth
Connect Euromag-link via Bluetooth using the dongle connected to a PC.
Fig. 45 Bluetooth Dongle (Part N° “DNG001”)

Click the menu button on the top right of the screen

Select

Select

On the Connection Window, select Mode -> Bluetooth

If desired Device is on the Paired Devices list, select and click

Click on to discover available devices, then select the device in the shown list to connect.

Close the Connection and the Settings Windows

Last connected device, will be available for fast connection on the Home screen
