Beta EVO 2T Handbook

1
GENERAL INFORMATION
15
GB
Key to colours
Bi = White
Ve = Green
Ma = Brown
Vi = Purple
Bl = Blue
Ne = Black
Gi = Yellow
Rs = Red
Ar = Orange
Az = Sky-blue
Ro = Pink
Gr = Grey
LEGEND ELECTRICAL DIAGRAM HOMOLOGATED VERSION
1) R.H. front turn signal with bulb 12V - 10W
2) Headlamp (double fi lament bulb) 12V-35/35W
3) Position light with bulb 12V - 5W
4) High beam indicator light with bulb 12V 12W
5) Dashboard indicator light with bulb 12V 1,3W
6) Turn signal indicator light with bulb 12V 1,3W
7) L.H. front turn signal with bulb 12V - 10W
8) Engine stop button
9) Horn button
10) Light switch
11) Turn signal switch
12) Stabilizer
13) Condenser 4700µF - 25V
14) Rear brake stop button
15) L.H. rear turn signal with bulb 12V - 10W
16) Tail light with bulb 12V - 5/21W
17) R.H. rear turn signal with bulb 12V - 10W
18) Switch for change mapping
19) Pick-up
20) Generator
21) H.T. coil
22) Electronic control unit
23) Regulator 12V
24) Thermal switch
25) Electrofan
26) Frame earth
27) Horn 12V
28) Front brake stop button

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
