CHECKS AND MAINTENANCE
36
GB
REPLACEMENT: VEHICLES
WITHOUT WATER DRAIN ON
HEAD COVER
Position the vehicle on a fl at base and in
a stable manner.
Replacement of the coolant must take place
when the engine is cold.
1) Unscrew cap 1.
2) Place a container under screw 2.
3) Unscrew the screw 2.
4) Drain the liquid.
5) Tighten screw 2 applying the specifi c
washer.
6) Position the vehicle as in the fi gure and
top up.
7) Tighten cap 1.
8) Reposition the vehicle on a fl at base
and switch it on.
9) Wait a few moments and then switch
off the engine.
10) Unscrew cap 1 and check the level.
If the level is not correct position the
vehicle as illustrated and top up.
11) Repeat the operation from step 7) to
step 10) until the circuit is perfectly
fi lled.
The amounts of liquid are shown on page
10.
1
2

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
