Beta EVO 2T Handbook

4
CHECKS AND MAINTENANCE
35
GB
COOLANT
CHECK THE LEVEL
Keep the vehicle in vertical position relative
to the ground.
The level of the coolant must be checked
when the engine is cold. Use the following
procedure:
Unscrew cap 1 and ensure that the liquid
is visible in the lower portion of the load-
ing tube.
Where the liquid is not visible in the lower
part of the loading tube position the vehicle
as in the fi gure and then top up.
Use the liquid indicated on page 18 in
the “Recommended lubricants and liquids”
table.
1

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
