Beta EVO 2T Handbook

4
CHECKS AND MAINTENANCE
33
GB
CHAPTER 4 CHECKS AND MAINTENANCE
CONTENTS
Key to symbols.....................................................................................34
Gear oil .............................................................................................. 34
Check the level ................................................................................ 34
Replacement ...................................................................................34
Coolant ..............................................................................................35
Check the level ................................................................................ 35
Replacement: vehicles without water drain on head cover .................... 36
Replacement: vehicles with water drain on head cover .........................37
Radiator grill ................................................................................... 38
Air fi lter ..............................................................................................38
Removing and fi tting air fi lter ............................................................38
Cleaning air fi lter ............................................................................39
Spark plug .......................................................................................... 40
Carburetor ..........................................................................................41
Draining the carburetor fl oat chamber ................................................41
Float level check .............................................................................. 42
Front Brake ..........................................................................................43
Check the level of the front brake fl uid ............................................... 43
Restoring the level of the front brake fl uid ...........................................43
Bleeding the front brake ................................................................... 44
Front brake lining control ..................................................................44
Rear brake ..........................................................................................45
Check the level of the rear brake fl uid ................................................ 45
Restoring the level of the rear brake fl uid ............................................45
Bleeding the rear brake .................................................................... 45
Rear brake lining control .................................................................. 46
Clutch control ......................................................................................47
Check oil level ................................................................................ 47
Bleeding clutch control ..................................................................... 47
Steering gear.......................................................................................48
Check of steering gear ..................................................................... 48
Oil fork ............................................................................................... 49
Removing legs ................................................................................. 49
Oil replacement right leg ..................................................................49
Oil replacement left leg .................................................................... 50
Legs assembly and parts ...................................................................51
Linkage rear suspension ...................................................................52
Tyres...................................................................................................53
Chain .................................................................................................54
Check and adjust tightening chain .....................................................54
Headlight ............................................................................................56
Replacing the headlight bulbs ........................................................... 56
Rear tail light ....................................................................................... 57
Cleaning the vehicle ............................................................................. 58
Prolonged inactivity .............................................................................. 59
Scheduled maintenance vehicle ............................................................ 60

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
