Beta EVO 2T Handbook

4
CHECKS AND MAINTENANCE
51
GB
LEGS ASSEMBLY AND PARTS
Apply the legs to the vehicle and tighten
the screws 1 to the torque indicated.
ATTENTION: Tightening of the screws
should be carried out by adjusting the
torque wrench to to the stability torque with
repeated tightening until stability torque has
been achieved.
Grease the wheel bolt.
Apply wheel and wheel bolt.
Apply brake caliper, disc cover and fender.
Tighten to the torque indicated.
Place the vehicle on the ground.
Compress and release the fork 3-4 times.
Tighten the wheel bolt and the screws of
the foot.
ATTENTION: Tightening of the screws
should be carried out by adjusting the
torque wrench to to the stability torque with
repeated tightening until stability torque has
been achieved.
Tighten to the torque indicated.
1
10Nm
10Nm
10Nm
25Nm
50Nm

Beta EVO 2T Specifications

General

Displacement	249 cc
Cooling System	Liquid cooled
Transmission	6-speed
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Dry Weight	67 kg
Engine Type	2-stroke single
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Fuel Capacity	2.5 liters
Frame	Aluminum
