Beta EVO 2T - Shock Absorber; Adjusting the Spring Preload; Adjusting the Rebound Damper

3
ADJUSTMENTS
31
GB
SHOCK ABSORBER
ADJUSTING THE REBOUND
DAMPER
The hydraulic brake unit in extension deter-
mines the behaviour in the extension phase
of the shock absorber and can be adjusted
using screw 1. Turning clockwise increases
the action of the brake in extension, while
rotating counter-clockwise decreases the
action of the brake in extension.
For standard calibration, refer to page
11.
NOTE:
for adjustment use a T-handle wrenches
with jointed hexagonal socket.
1
ADJUSTING THE SPRING
PRELOAD
Spring preload is adjusted by means of
screw 2. Turning clockwise will increase
the preload, while rotating counter- clock-
wise decreases the preload.
For standard calibration, refer to page
11.
2
